Super Duplex Steel S32760 Forgings are prized for their remarkable strength, impressive resistance to corrosion, and outstanding durability, especially in tough industrial settings. Crafted with precision, these forgings offer excellent mechanical stability, toughness, and long-lasting reliability. Their ability to resist pitting, crevice corrosion, and stress corrosion cracking makes them perfect for critical roles in the oil and gas, chemical processing, petrochemical, and marine sectors. S32760 forgings guarantee structural integrity and performance even under the most demanding conditions, providing reliable and high-performance solutions for challenging industrial tasks.
Super Duplex Steel S32760 Forgings are made from a high-alloy stainless steel that contains around 25–26% chromium, 6–7% nickel, and 3–4% molybdenum, along with trace amounts of nitrogen and other elements. This unique blend gives them exceptional resistance to corrosion caused by chlorides and acidic environments, while also delivering superior mechanical properties. In terms of mechanics, these forgings showcase high tensile and yield strength, excellent toughness, and good ductility. The combination of their corrosion resistance and mechanical performance ensures that S32760 forgings remain reliable and durable, even in high-pressure, high-temperature, and chemically aggressive situations.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32760 | 0.05 max | 1.00 max | 1.00 max | 0.030 max | 0.010 max | 24.00 – 26.00 | 3.00 – 4.00 | 6.00 – 8.00 | 0.20 – 0.30 | 57.61 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S32760 | 7.8 | 0.281 | 1350 | 2460 |
| STANDARD | WERKSTOFF NR. | UNS |
| Super Duplex S32760 | 1.4501 | S32760 |
Yes, Super Duplex Steel S32760 forgings are highly suitable for offshore and marine applications due to their excellent corrosion resistance, high strength, and resistance to pitting, crevice corrosion, and chloride stress cracking.
Welding processes compatible with Super Duplex Steel S32760 forgings include Tungsten Inert Gas (TIG), Metal Inert Gas (MIG), and Shielded Metal Arc Welding (SMAW), using matching filler materials to maintain corrosion resistance.
Super Duplex Steel S32760 forgings are governed by ASTM A182, ASTM A240, ASME SA-182, and EN 10088-3 standards, ensuring quality, corrosion resistance, and mechanical properties for demanding industrial applications.
Super Duplex Steel S32760 Forgings find extensive use in the oil and gas, chemical processing, marine, and desalination industries. They are perfect for creating valves, flanges, pumps, pipe fittings, pressure vessels, and heat exchangers where both corrosion resistance and high mechanical strength are essential. In marine and chemical applications, they deliver long-lasting performance against seawater, chlorides, and acidic substances. Moreover, S32760 forgings are utilized in offshore pipelines, high-performance industrial machinery, and structural components, providing exceptional durability and reliability.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
