Located in the heart of Kinshasa, Congo, Sadiki Metals stands as a dedicated partner for industry, specializing in the production and supply of high-performance Inconel X-750 bars and rods. We understand the demanding environments our clients operate in, which is why we are committed to delivering materials engineered for exceptional strength and reliability. Our focus is on providing local and international sectors with the robust components they need to build and maintain critical infrastructure and machinery with unwavering confidence.
The exceptional character of Inconel X-750 comes from its unique composition, primarily nickel and chromium enhanced with significant additions of aluminum and titanium. This specific formula allows the alloy to be thermally treated, resulting in outstanding mechanical properties. It maintains impressive tensile and yield strength even under extreme heat, while also offering excellent resistance to creep and relaxation, making it a truly resilient material under sustained stress.
Specification : ASTM B 637 / ASME SB 637, AMS 5669, AMS 5698, AMS 5699
Dimensions : ASTM, ASME and API
Size : 5 mm To 500 mm
Diameter : 0.1 mm to 100 mm
Length : 100 mm To 3000 mm Long & Above
Finish : Bright, Polish & Black
Grade : Inconel X-750 – UNS N07750
Form : Round, Square, Hex (A/F), Rectangle, Wire (Coil Form), Wire-mesh, Billet, Ingot, Forging Etc.
Our Inconel X-750 Round Bars conforms to NACE MR0175/ISO 15156
| Grade | Ni | Cr | Al | C | Mn | Ti | Cu | Si | S |
| Inconel X-750 | 70.0 min | 14.0 – 17.0 | 0.40 – 1.0 | .08 max | 1.00 max | 2.25 – 2.75 | 0.50 max | .50 max | .01 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.28 g/cm3 | 1430°C | 1267 MPa | 868 MPa | 25 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Inconel X750 | 2.4669 | N07750 |
| Temperature, °F | Mean Linear Expansion, in./in./°F x 10-6 from 70° F to Temperature Shown | Thermal Conductivity, Btu/in./hr/sq ft/°F | Specific Heat Btu/lb/°F | Diffusivity, sq ft/hr | Electrical Resistivity, ohm/circ mil/ft |
|---|---|---|---|---|---|
| -100 | 6.7 | 74 | 0.090 | 0.135 | – |
| 70 | – | 83 | 0.103 | 0.132 | 731 |
| -250 | 6.5 | 67 | 0.073 | 0.150 | – |
| -200 | 6.6 | 70 | 0.080 | 0.143 | – |
| 600 | 7.5 | 109 | 0.120 | 0.148 | 761 |
| 800 | 7.8 | 120 | 0.125 | 0.158 | 771 |
| 200 | 7.0 | 89 | 0.109 | 0.133 | 739 |
| 400 | 7.2 | 98 | 0.116 | 0.140 | 746 |
| 1000 | 8.1 | 131 | 0.130 | 0.169 | 783 |
| 1600 | 9.3 | 164 | 0.171 | 0.164 | 761 |
| 1800 | 9.8 | – | – | – | – |
| 1200 | 8.4 | 143 | 0.137 | 0.173 | 786 |
| 1400 | 8.8 | 154 | 0.151 | 0.172 | 775 |
Inconel X750 bars/rods are widely used in chemical processing, pollution control, and marine industries due to their superior corrosion resistance and durability in aggressive environments.
Yes, Inconel X750 bars/rods offer excellent resistance to strong acids like sulfuric, hydrochloric, and phosphoric acids, making them ideal for highly corrosive applications.
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@sadikimetals.com
The remarkable capabilities of these bars and rods make them indispensable in fields where failure is not an option. You will find them forming the backbone of jet engines and gas turbines, withstanding incredible temperatures and pressures. They are also crucial in nuclear reactors, aerospace components, and high-stress tooling for forming and extrusion processes. Essentially, wherever intense heat, high stress, and corrosive conditions converge, Inconel X-750 provides the durable, long-lasting performance that engineers and manufacturers rely on.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Sadiki Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Kinshasa, Congo
