Titanium Flat Bars are prized for their incredible strength, lightweight nature, and resistance to corrosion, making them perfect for tough industrial, aerospace, marine, and chemical applications. Crafted with precision, these flat bars offer outstanding mechanical stability, durability, and long-lasting performance even in the harshest environments. Their flat shape makes them easy to fabricate, machine, and assemble into both structural and functional components. With their excellent resistance to seawater, chemicals, and oxidation, titanium flat bars are a go-to choice in industries where strength and corrosion resistance are essential, ensuring reliable performance in high-performance engineering tasks.
Typically, Titanium Flat Bars are made from commercially pure titanium or titanium alloys, often mixed with elements like aluminum, vanadium, or molybdenum to boost strength, hardness, and corrosion resistance. Mechanically, they deliver high tensile strength, impressive fatigue resistance, and remarkable toughness, even when temperatures rise. These bars maintain their shape under mechanical stress and thermal cycling, while also providing superior resistance to chemical attacks, oxidation, and stress corrosion cracking. Their blend of lightweight, strength, and durability makes titanium flat bars incredibly versatile for both structural and high-performance uses.
| Standard | ASTM B348, ASME B348, ASTM B863, ASTM F67, ASTM F136 |
| Application | Industrial and Medical |
| Shape | Flat |
| size | Dia 5.0~350 X ≤ 6000 |
| Grade | Gr1, Gr2, Gr3, Gr4, Gr5, Gr7,Gr23,Ti15333 |
| Density | 4.53 g/cm3 |
| Techniques | Forged,Rolled, Extrusion |
| Surface | Hot Rolled Pickled or Sand Blasting Finished, Cold Drawn, Bright, Polished, Hairline |
| Technique | TC4 Titanium Alloy Hot Rolled, Cold Rolled, Cold Drawn, Forged |
Hardness, Brinell | 120 | 120 | annealed |
Hardness, Knoop | 132 | 132 | Estimated from Brinell. |
Hardness, Rockwell B | 70 | 70 | annealed |
Hardness, Vickers | 122 | 122 | Estimated from Brinell |
Tensile Strength, Ultimate | 240 MPa | 34800 psi | – |
Tensile Strength, Yield | 170 – 310 MPa | 24700 – 45000 psi | – |
Elongation at Break | 24 % | 24 % | – |
Reduction of Area | 35 % | 35 % | – |
Modulus of Elasticity | 105 GPa | 15200 ksi | In Tension |
Compressive Modulus | 110 GPa | 16000 ksi | – |
Poisson’s Ratio | 0.37 | 0.37 | – |
Charpy Impact | 310 J | 229 ft-lb | V-notch |
Shear Modulus | 45 GPa | 6530 ksi | – |
|
Physical Properties |
Metric |
English |
|
Density |
4.51 g/cc |
0.163 lb/in³ |
| Physical Properties | Metric | English |
|---|---|---|
| Density | 4.51 g/cc | 0.163 lb/in³ |
|
STANDARD |
WERKSTOFF NR. |
UNS |
|
Titanium |
3.7035 / 3.7165 / 3.7235 |
R50400 / R56400 / R52400 |
Titanium Flat Bars are commonly used in the aerospace, medical, and chemical industries for components like frames, brackets, and heat exchangers due to their strength and corrosion resistance.
Yes, Titanium Flat Bars can be welded, but they require precise control over heat to avoid contamination and maintain the material’s strength and corrosion resistance.
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@sadikimetals.com
You’ll find Titanium Flat Bars in a variety of industries, including aerospace, marine, chemical processing, medical, automotive, and power generation. They’re perfect for structural components, machine parts, frameworks, pressure vessels, and equipment that face corrosive media or extreme conditions. In chemical and marine settings, they offer long-lasting durability, while in medical applications, their biocompatibility guarantees safety and reliability for implants and surgical tools. Additionally, titanium flat bars are utilized in offshore engineering and precision machining, showcasing their adaptability across various fields.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
