Nestled in the heart of Kinshasa, Sadiki Metals stands as a trusted partner for industry, bringing the exceptional quality of Stainless Steel 316 square bars and rods directly to the local market. We understand the demanding conditions faced by Congolese projects, which is why we specialize in supplying this superior-grade alloy. Our commitment is to provide fabricators, engineers, and builders with materials that offer not just strength, but remarkable resilience against corrosion, ensuring the longevity and success of your most critical applications right here at home.
The strength of Stainless Steel 316 lies in its sophisticated composition, which includes a crucial addition of molybdenum alongside its chromium and nickel content. This powerful combination gives the material its signature resistance to pitting and corrosion, particularly from chlorides like salt. The resulting square bars and rods are not only tough and durable, exhibiting high tensile and yield strength, but they also maintain excellent ductility. This means they can be machined, welded, and formed into complex components without sacrificing their inherent structural integrity or corrosion-fighting properties.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 316 | 0.08 | 18.0 | 2.00 | 14.0 | 0.045 max | 0.03 max | 0.75 max |
| Element | Density, lb/in3 | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 316 | – | – | 515 Min | 205 Min | 40% Min |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | – | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Stainless Steel 316 square bars are resistant to galvanic corrosion when used in environments with similar metals. However, when coupled with dissimilar metals, they can be susceptible to galvanic corrosion if exposed to electrolytes.
Stainless Steel 316 square rods are available in various sizes ranging from 1/8" to 6" or more, depending on the supplier. They are typically offered in finishes such as mill, polished, or brushed, based on customer requirements.
Yes, Stainless Steel 316 square bars are highly resistant to corrosion, making them suitable for underground applications. Their durability and resistance to rust make them ideal for use in harsh environments.
Because of its robust nature, Stainless Steel 316 is the go-to choice for projects where failure is not an option. You’ll find these square bars and rods forming the backbone of marine hardware, chemical processing equipment, and pharmaceutical machinery, where they brave harsh, corrosive environments daily. They are equally vital in our local food and beverage industry, in architectural structures along the coast, and in critical surgical instruments. Essentially, wherever strength and impeccable corrosion resistance are paramount, this material provides a reliable and long-lasting solution for builders and manufacturers.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
