Nestled in the vibrant industrial heart of Kinshasa, Sadiki Metals has built a strong reputation for reliability and expertise. We take pride in our role as a dedicated manufacturer and supplier, specializing in the production of high-performance Monel K500 forgings. Our commitment is to deliver components that not only meet but exceed the rigorous demands of various critical industries, providing our clients in Congo and beyond with durable solutions they can trust for their most challenging applications.
The strength of Monel K500 lies in its unique composition, which builds upon the excellent corrosion resistance of the Monel family by adding aluminum and titanium. This allows the alloy to be age-hardened, resulting in forgings that possess a remarkable combination of high strength and exceptional toughness. These components maintain good ductility and offer superb resistance to both corrosion and seawater, making them far more robust than their non-hardened counterparts.
Specifications ASTM B564 / ASME SB564
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
Grades Monel K500 Forging UNS (N05500), DIN (2.4375)
BS3072 NA18, QQ-N-286, DIN 17750, ISO 6208
AMS 4676, BS3076 NA18, ASTM B 865, DIN 17752, QQ-N-286, ISO 9723
AMS 4676, ISO 6208, ASTM B 865, DIN 17752, QQ-N-286
BS3076, NA18, DIN 17753, QQ-N-286, ISO 9724
DIN 17754, QQ-N-286, ISO 9725
UNS N05500, BS6076 NA13, Werkstoff Nr. 2.4375, MIL-N-24549, NACE MR-01-75
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 115000 , MPa – 790 | Psi – 160000 , MPa – 1100 | 20 % |
| STANDARD | UNS | WNR. |
| Monel K500 | N05500 | 2.4375 |
Temperature control during the forging of Monel K500 ensures optimal microstructure, improving strength, toughness, and corrosion resistance. It prevents defects like cracking and ensures consistent quality.
To improve the surface finish of forged Monel K500 parts, use techniques like polishing, grinding, or shot peening. Additionally, applying chemical treatments such as pickling can help remove oxides and enhance smoothness.
To determine if Monel K500 forgings meet your needs, evaluate their mechanical properties, corrosion resistance, and compliance with industry standards.
Because of this outstanding blend of properties, Monel K500 forgings are indispensable in environments where failure is not an option. You will find them as essential components in marine engineering, such as propeller shafts and pump impellers, where they withstand the relentless assault of saltwater. They are also crucial in the oil and gas industry for tools and instruments, as well as in chemical processing equipment, where their resistance to corrosive substances ensures long-lasting, reliable performance under intense pressure.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
